A fully automatic pallet magazine places the fully stacked pack on pallets or polystyrene blocks. The position information comes from a package parts list that is managed in the control system. The completed package is then moved through the wrapping machine and transported away.

(Click to enlarge)
Structure of a pack parts lists
Pallet arrangement for a fully stacked pack

Hardware layout:

  • Approx. 10 inverter drives
  • 1 x SIEMENS-PLC 317-2 DP
  • Approx. 350 inputs/outputs


  • Reliable step sequence programming
  • Material tracking in the control system
  • Pack parts lists for pallet and polystyrene arrangements in the control system
  • Various wrapping programs (e.g. wrap complete pack, only wrap on pallet,...)
  • and much more
